Specification
| Model | FC-6512-005 |
| Wavelength | 650nm |
| Laser Class | Class IIIA |
| Output Power | >-4dBm @ |
| Spectral Width | <20nm |
| Transmission | Continuous or 3Hz pulsed signal |
| Range | Visibility to |
| Power Source | 3V (2*AAA battery) |
| Operating Temp | 0 to + |
| Storage Temp | 0 to + |
| Length | 146mm |
| Diameter | 13.5mm |
| Connector Style | Universal (Accept any connector with a |
NOTE: Do not look into the path of the laser beam. Laser radiation is potentially harmful, direct eye contact with laser beam may cause eye injury and therefore should be avoided all cost. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
